Description
CPU Support
Supports AMD Ryzen 7000 series desktop processors
Supports AMD Ryzen 8000 series desktop processors
Supports AMD Ryzen 9000 series desktop processors
- Supports AM5 socket processors
chipset
AMD B850 chipset
Memory support
x DDR5 memory slots
- Only supports DDR5 memory
- Up to 8000 MT/S(OC)
- Maximum system memory capacity: 48GB * 4, totaling 192GB
- Supports dual-channel memory technology
- Supports Extended Overclocking Configuration (EXPO) memory modules and Extreme Memory Configuration (XMP)
Expansion slots
1 PCIE 5.0x16 slot
1 PCIE 4.0 x4 slot
1 PCIE 4.0 x2 slot
Storage interface
1x M.2 supports up to PCIe 5.0 X4 (depending on CPU support)
2x M.2 supports up to PCIe 4.0 x4
4x SATA 6Gb/s ports
Audio
Realtek® ALC897 high-fidelity decoding chip (supports up to 5.1 channels)
Onboard network card
Realtek® RTL8125GB network controller
- Support 2.5G wired network
Wi-Fi 6 module
- Support 802.11 a/b/g/n/ac/ax
- Support 2.4GHz/5GHz wireless frequency band
- Support Bluetooth 5 wireless transmission
Rear I/O interface
1 DisplayPort interface
1 HDMI port
4 USB 2.0 ports
3 USB 3.2 GEN2 Type-A ports
1 USB 3.2 GEN2 Type-C port
1 LAN (RJ45) port
2 WiFi6 antenna interfaces
6 audio jacks
Front expansion interface
1 USB 2.0 pin can be expanded to 2 USB 2.0 ports (FUSB2.0_1)
1 USB 3.2 Gen 1 pin can be expanded to 2 USB 3.2 Gen 1 Type-A ports (FUSB3.0)
1 USB 3.2 Gen 1 5G pin can be expanded to 1 USB 3.2 Gen 1 5G Type-C interface (F_USBC)
Onboard pins
1 CPU fan pin (CPU_FAN)
1 water cooling pump pin (AIO_PUMP)
3 system fan headers (CHA_FAN1, CHA_FAN2, CHA_FAN3)
1 front audio pin (F_AUDIO)
1 front panel pin (F_PANEL)
3 5V ARGB pins (5V_ARGB_1, 5V_ARGB_2, 5V_ARGB_3)
1 12V RGB pin (12V_RGB1)
1 speaker pin (SPEAK)
1 serial port pin (COM)
1 Clear CMOS jumper (CLR_CMOS)
1 Flash BIOS header (FL_BIOS1)
1 BIOS burner pin (JBIOS)
1 diagnostic card pin (ESPI_HEADER)
Motherboard specifications
ATX form factor: 305mm x 245mm
