Description
Chipset
AMD® A620A
CPU Support
Supports AMD Socket AM5 Processors including Ryzen™ 9000 / 8000 / 7000 Series Desktop Processors
Memory Support
2x DIMMS, Dual Channel DDR5, Maximum Memory Capacity 64GB(2x 32GB), up to 7600 MHz(OC)
PCI-E Expansion Slots
1x PCIe 4.0 x16, 1x PCIe 3.0 x4
Display Connector
DisplayPort x1, HDMI x1
Audio
Realtek® ALC897 HD Audio, 5.1 Channel
Network
Realtek® RTL8111K Gigabit Ethernet
Front USB Headers
1x USB 3.2 Gen1 (2 x Type-A),
1x USB 2.0 (4 x Type-A)
Rear Ports
1× HDMI ™, 1× DisplayPort, 1× PS/2
4× USB 2.0, 2× USB 3.2 Gen 1 Type-A
1× LAN (RJ45), 2× Wi Fi Antennas
3× Audio Jacks
4× USB 2.0, 2× USB 3.2 Gen 1 Type-A
1× LAN (RJ45), 2× Wi Fi Antennas
3× Audio Jacks
Storage
1x PCIe 4.0 M.2, 1x PCIe 3.0 M.2, 4x SATA
Dimensions
Micro-ATX, 244x235mm
Debug LED
DRAM: Yellow, CPU: Red, GPU: White, Boot: Green
