Description
| Management Type | L2 Web Managed |
| Number of Ports | 30 |
| 10GbE SFP+ | 2 |
| 10GbE BASE-T (RJ45) | 2
10G/5G/2.5G/1G/100M
|
| 10GbE SFP+/RJ45 Combo Ports | 2
Note: The 10GbE SFP+ ports are backward compatible with 1GbE SFP; the RJ45 (copper) combo port supports up to five speeds (10G/5G/2.5G/1G/100M).
|
| 2.5GbE (RJ45) | 24 |
| Total PoE Ports | 28 |
| PoE++ PSE (802.3bt, 90W) | Port 17-28 (90W) |
| PoE Power Output | Port 1-16 (45W) Port 17-28 (90W) |
| Total PoE Power Budget | 375W |
| Power Supply Description | Internal Power supply unit |
| Max. Power Consumption | 455W |
| Input Power Type | AC |
| Input Voltage Range | 100-240VAC, 50/60Hz |
| MAC Address Table | 32K |
| Total Non-Blocking Throughput | 120Gbps |
| Switching Capacity | 240Gbps |
| Management Interface | Web |
| Console | RJ45 |
| Energy Efficient Ethernet (IEEE 802.3az complaint) | |
| Fan | PWM VAPO Bearing fan x 3 |
| Sound Level | <28dB db(A) |
| Supported Standards | IEEE 802.3bz 2.5G/5GBase-T IEEE 802.3an 10GBASE-T IEEE 802.3ae 10G Fiber IEEE 802.3z 1000BASE-SX/LX IEEE 802.3bt Power over Ethernet IEEE 802.3x Full-Duplex Flow Control IEEE 802.1Q VLAN Tagging IEEE 802.1w RSTP IEEE 802.3ad LACP IEEE 802.1AB LLDP IEEE 802.1p Class of Service IEEE 802.3az EEE |
| Form Factor | Rackmount |
| LED Indicators | Per Port: Speed/Link/Activity Per System: Power/Loop |
| Buttons | Reset button |
| Dimensions (HxWxD) | 44 x 440 x 205 mm |
| Weight (Net) | 7.8 lbs |
| Weight (Gross) | 9.7 lbs |
| Operating Temperature | 0°C to 50°C (32°F to 104°F) |
| Relative Humidity | 5~95% Non-condensing |
| Certifications | CE, VCCI, BSMI, FCC, ICES, RCM, UKCA, LVD |
| Electromagnetic Compliance | CLASS A |
| Jumbo Frames | 12K |
| Warranty | 2 Years |
