Description
Cooler Specification
Intel Xeon LGA4677
Height (without fan)
158mm
Width (without fan)
125mm
Depth (without fan)
45 mm
Weight (without fan)
626g
Height (with fan)
158mm
Width (with fan)
125mm
Depth (with fan)
97mm
Weight (with fan)
1018g
Material
Copper (base and heat-pipes), aluminum (cooling fins), soldered joints & nickel plating
157
Max.TDP
see NSPR
Fan compatibility
120x120x25
Scope of delivery
- 2x NF-A12x25 PWM premium fan
- NA-YC1 4-pin PWM y-cable
- NT-H1 high-grade thermal compound (pre-applied)
- SecuFirm2™ mounting kit for LGA4677
- NM-SMT5 Torx® T30 mounting tool
- Noctua metal case-badge
6 Years
FAN Specification
Model
Bearing
Max. rotational speed (+/- 10%)
2000RPM
Min. rotational speed @ 20% PWM (+/-20%)
450RPM
102,1 m³/h
Max.acoustic noise
22,6 dB(A)
Input power (max.)
1,68 W
Voltage range
12 V
MTTF
> 150.000 hours
