Description
| Model | Mini WorkStation MS-01 |
| Processor | Intel® Core™ i9-13900H, 14 Cores / 20 Threads, turbo up to 5.4GHz, 24 MB Intel® Smart Cache |
| Graphics | Intel® Iris® Xe Graphics (up to 1.5GHz) |
| Memory | DDR5-5200MHz Dual Channel (SODIMM slots x 2, up to a total maximum of 64GB) |
| Storage |
M.2 2280 NVMe SSD slot (Alt U.2) (PCIe 4.0 x4) x 1 M.2 2280/22110 NVMe SSD slot (PCIe 3.0 x4) x 1 M.2 2280/22110 NVMe SSD slot (PCIe 3.0 x2) x 1 |
| Expansion Slot | 1 x PCIe 4.0 x16 slot (Half-height, single-slot, supports up to PCIe 4.0 x8 speed) |
| Video Output | 1 x HDMI (2.0) (4K@60Hz) 2 x USB-4 (8K@30Hz) |
| Audio Output | 1 x HDMI (2.0) 1 x 3.5mm combo jack |
|
Wireless Connectivity |
M.2 2230 Wi-Fi support (Wi-Fi 6, Bluetooth 5.2) |
| Ethernet | 10Gbps SFP+ LAN x 2 2.5Gbps RJ45 LAN x 2 |
| I/O Ports |
HDMI x 1 USB-4 ports x 2 (Alt PD) USB 3.2 Gen2 Type-A ports x 2 USB 3.2 Gen1 Type-A ports x 2 USB 2.0 ports x 2 10G SFP+ ports x 2 RJ45 2.5G Ethernet ports x 2 3.5mm combo jack x 1 |
| Power Supply | DC 19V (including power adapter) |
| Operating System | |
| Dimensions | 196 x 189 x 48 mm |
