Description
Specifications
| CPU | 13th Gen Intel® Core™ i5-13500H 12 Cores / 16 Threads Intel 7 Process, Max Boost Clock: 4.7 GHz 18 MB Cache Power Modes: Silent Mode: 28W Balanced Mode: 35W Performance Mode: 40W (Peak 45W) Copper Pipe + Single Fan Cooling (Silent Design) |
|---|---|
| GPU | Intel® Iris® Xe Graphics Max Dynamic Frequency: 1.45 GHz 80 Execution Units (EU) |
| Memory | 2× DDR4 SO-DIMM, 3200 MT/s 16GB / 32GB Options (Dual Channel Required) Max Support: 64GB (32GB×2) Motherboard does not support DDR5 |
| Storage | M.2 2280 NVMe PCIe 3.0 512GB / 1TB Options Motherboard supports PCIe 4.0 Expandable Storage: M.2 2280 PCIe 4.0 ×4 up to 8TB (SATA SSD Not Supported) M.2 2242 supports SATA3.0 and PCIe3.0 ×4, up to 8TB Dual SSD Slots |
| Video Output | Dual HDMI + Type-C Triple Display Output Supports up to 4K Resolution |
| Front I/O | • 2× USB3.2 Gen2 Type-A (10Gbps) • 1× USB3.2 Gen2 Type-C (DP 4K@60Hz, no charging) • 1× 3.5mm Audio Jack (CTIA) |
| Rear I/O | • 2× USB3.2 Gen1 Type-A (5Gbps) • 2× HDMI 2.0 (4K@60Hz) • 1× DC IN (5.5/2.5mm, 20V/5A) • 2× RJ45 2.5G LAN • 1× Lock Slot • 1× Power Button |
| Network | Wi-Fi 6 Max Speed: 1201 Mbps Bluetooth 5.2 |
| Power | Built-in Button Battery DC IN (5.5/2.5mm), 20V/5A, 100W |
| Dimensions | 128.5 × 127 × 51 mm (Without Feet) |
| Weight | Approx. 480 g (Barebone) |
| OS | Windows 11 Pro |
