Description
Specifications
| Case Type | Mid Tower |
| Material | Steel T1.0, Tempered Glass T4.0 |
| Product Dimension ( H x W x D ) | 500 × 230 × 500mm, 19.7" × 9.1" × 19.7" |
| Drive Bay | Max: 3x3.5'', 3x2.5''/ 6x2.5'' tray |
| M/B Compatibility |
E-ATX (12"×13"), ATX, Micro-ATX, Mini-ITX |
| Power Supply | PSII: ATX 12V (Length < 220 mm) |
| I/O Ports | USB 3.0 x 2, USB 2.0 x 2, HD Audio (CTIA-SPK/MIC), Type-C USB3.1 Gen.2 |
| Expansion Slots(Maximum Space) | PCI-E x 7: Length<400mm (No Cooling of bottom) / Width <175mm Lateral PCI-E x 3: Length<412mm (No Cooling of bottom) / Width<150mm (CPU Heatsink Height<105mm) / Height<65mm |
| Thermal Solution |
Top: 120mm Fan x 1 120mm Radiator (Optional) Rear: 120/140mm Fan x 3 420mm Radiator(Length<470mm / Thickness < 55mm) (Optional) 360/280mm Radiator (Length<400mm / Thickness < 65mm) (Optional) Bottom: 120/140mm Fan x 3 360/280mm Radiator (Length < 485mm) (Optional) |
| CPU Heatsink |
Height<170mm |
