Description
Specifications
| Model | 6 |
| Case Type | Mid Tower |
| Material | Steel T0.8, Tempered Glass T4.0 |
| Product Dimension ( H x W x D ) | 450 x 215 x 450 mm, 17.7" x 8.5" x 17.7" |
| Drive Bay | Max: 4 x 3.5”/2.5” tray |
| M/B Compatibility |
E-ATX (12” x 11”), ATX, Micro - ATX, Mini - ITX |
| Power Supply | PSII: ATX 12V (Length < 180 mm) |
| I/O Ports | USB 3.0 x 2, HD Audio (CTIA-SPK/MIC) |
| Expansion Slots(Maximum Space) | PCI-E x 7: Length <350mm (No Cooling of bottom) / Width <165mm Lateral PCI-E x 2: Length <360mm (No Cooling of bottom) / Width <165mm / Height<54mm |
| Thermal Solution |
Top: 120mm Fan x 1 120mm Radiator (Optional) Front: 120mm Fan x 3 / 140mm Fan x 2 (Optional) 240/280mm Radiator ( Length < 361mm / Thickness is related to the height limit of the main board ) (Optional) Bottom: 120/140mm Fan x 3 (Optional) 360/280mm Radiator (Length < 440mm) (Optional) |
| CPU Heatsink |
Height < 162mm |
