| Video Input |
| Interfaces |
1 x HDMI Type A Female (Black) |
| Impedance |
100 Ω |
| Max. Distance |
3m @3840x2160@30Hz (4:4:4) |
| Video Output |
| Interfaces |
2 x HDMI Type A Female (Black) |
| Impedance |
100 Ω |
| Max. Distance |
15m @3840x2160@30Hz (4:4:4) |
| Video |
| Max. Data Rate |
10.2 Gbps (3.4 Gbps Per Lane) |
| Max. Pixel Clock |
340 MHz |
| Compliance |
HDMI (3D, Deep Color, 4K);
HDCP Compatible |
| Max. Resolution |
Up to 4096 x 2160 / 3840 x 2160 @ 60Hz (4:2:0);
4096 x 2160 / 3840 x 2160 @ 30Hz (4:4:4) |
| Audio |
| Input |
1 x HDMI Type A Female (Black) |
| Output |
2 x HDMI Type A Female (Black) |
| Connectors |
| Power |
1 x DC Jack |
| Environmental |
| Operating Temperature |
0-50 °C |
| Storage Temperature |
-20 - 60 °C |
| Humidity |
0 - 80% RH, Non-Condensing |
| Physical Properties |
| Housing |
Metal |
| Weight |
0.31 kg ( 0.68 lb ) |
| Dimensions (L x W x H) |
12.50 x 8.00 x 2.50 cm
(4.92 x 3.15 x 0.98 in.) |
| Carton Lot |
20 pcs |
| Power Consumption |
DC5.3V:3.12W:15BTU/h
Note:
● The measurement in Watts indicates the typical power consumption of the device with no external loading.
● The measurement in BTU/h indicates the power consumption of the device when it is fully loaded. |
| Note |
For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format. |
