APC
Price:
HK$126,450.00

Description

Specifications

Overview
Lead time 通常貨源充足
主
Run time for load
W
information_stroke

Min-max: 2000-20000 W
3min 1s
Max. Capacity Used
information_stroke
100 %


Main Input Voltage 380...415 V 3 相
230 V
Other Input Voltage 220...240 V
Main Output Voltage 380...415 V 3 相
230 V 1 相
Other Output Voltage 230 V
额定功率 [W] 20000 W
额定功率 [VA] 20000 VA
Output connector type 硬接線 5-線（3PH + N + G） 1
硬接線 3-線 （1PH+N+G） 1
IEC connector 3-線 （1PH+N+G） 1
机架单元数 7U
設備提供 1 x USB 纜線
1 x 機架式支架
1 x stabilization/wall mounting feet
1 x installation manual
電池與運轉時間
Run Time View Runtime Graph
action_new_window
Efficiency View Efficiency Graph
action_new_window
电池类型 封的電池
預安裝的電池 0
空電池槽 0
典型充電時間 4 小时
RBC™ 數量 2
电源电压 +/- 192 V
電池充電功率（瓦特） 2160 W rated
电池使用寿命 3…5 年
Venturi Pipe APCRBC172
action_new_window
可延伸運轉時間 1
通用
拓樸 在線雙變換式
Number of power module free slots 0
Number of power module filled slots 0
Redundant No
實體標示
顏色 黑色 RAL 9005)
高度 30.6 cm
寬度 44.0 cm
深度 70.0 cm
產品重量 142.5 kg
安装位置 正面
Mounting preference Lower
安裝類型 Rack-mounted
Two post mountable 0
USB compatible Yes
安装位置 水平方向
輸入
網絡頻率 40...70 Hz auto-sensing
Number of input connectors 1 硬接線 5-線（3PH + N + G）
1 硬接線 3-線 （1PH+N+G）
滿載時的效率 160...285 V 全负荷
380 V 380...415 V
最大輸入電流 87 A
开关电流能力 125 A
輸入電壓總失真 少于5%的滿負荷
Input current 87 A
Load power factor From 0.9 leading to 1 lagging
輸出
Maximum configurable power in VA 20000 VA
最大可配置功率 (W) 20000 W
輸出頻率（與市電同步） 50/60 Hz +/- 4 Hz 與市電同步
Wave type 正弦波
過載操作 60 秒 @ 125% 和 30 秒 @ 150%
滿載時的效率 94 %
谐波失真 低于 5%
波峰系数 3 : 1
bypass type 內部旁路（自動與手動）
其它参数 可配置 380︰400 或 415V 3 相額定輸出電壓
認證與保固
產品証明 CE
UKCA
TISI
標準 EN/IEC 62040-1:2019/A11:2021
EN/IEC 60204-2
環境
工作環境溫度 0…40 °C
相對濕度 0…95 % 非凝结
運行高度 0...3000 m
存儲環境溫度 -15…45 °C
相對貯藏濕度 0…95 % 非凝结
存储高度 0…15000 m
声响级别 58 dBA
热消散 3821 Btu/h
IP防護等級 IP20
交流與管理
空闲槽 0
預安裝的 SmartSlot™ 卡 Network management card 3 with environmental monitoring
alarm Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
緊急關機 (EPO) 是的
突波保護與篩選
突波吸收能力 600 J
篩選 全天候多柱噪音過濾︰0.3% ieee 突波限制︰零箝拉回應時間︰符合 ul 1449
Packing units
Unit Type of Package 1 PCE
Number of Units in Package 1 1
Package 1 Height 53.5 cm
Package 1 Width 79.0 cm
Package 1 Length 59.0 cm
Package 1 Weight 157.2 kg
合約保證
保養 3 years repair or replace (excluding battery) and 2 years for battery
