APC
Price:
HK$199,999.00

Description

Specifications

Overview
Presentation High-efficiency 3-phase UPS that features advanced product features, competitive specifications, and robust electrical design, making business continuity easy in the data center or electrical room. This is an exceptionally easy to install, operate, maintain, and service 30 kVA UPS , ideal for small and medium businesses. Includes dust filter and conformance-coated boards for harsh environments. This UPS is for internal batteries, but is supplied without batteries, so you can easily customize the battery runtime. For battery runtime details, see the runtime charts published under the Documents tab.
Lead time Usually delivered within 6 weeks
host
Main Input Voltage 400 V 3 phase
Other Input Voltage 380V
415 V
Main Output Voltage 400 V 3 phase
Other Output Voltage 380 V
415 V
Rated power [W] 30kW
Rated power [VA] 30 kVA
Equipment provided Dust Filter Installation Guide
Battery and run time
Efficiency View Efficiency Graph
action_new_window
Battery Type VRLA
voltage 240V
Maximum short-circuit current 10 kA
Pre-installed battery 0
Empty battery slot 4
entity mark
color White RAL 9003)
high 140cm
width 50 cm
depth 96.9cm
product weight 152kg
USB compatible Yes
enter
Maximum input current 55A
Input voltage total distortion Under full load conditions, less than 3%
Load power factor 0.9 ahead to 0.9 behind
Input Power Factor at Full Load 0.99
Efficiency at full load 304...477 V
Network frequency 45...65 Hz
output
Maximum configurable power in VA 30 kVA
Maximum configurable power (W) 30kW
Output frequency (synchronized with mains) 50 Hz synchronized with mains
60 Hz synchronized with mains
harmonic distortion less than 3%
Output voltage total distortion (THD) < 3% linear load
Output voltage tolerance +/- 1.5%
topology Online double conversion
Certification and Warranty
Product certification CE
EAC
RCM
environment
Working temperature 0…40°C
Relative humidity 0…95 % non-condensing
operating height 0...3333 ft
Storage environment temperature -15…40 °C
relative storage humidity 0…95 % non-condensing
Storage height 0.00…15240.00 m
sound level 63 dBA
heat dissipation 1410W
IP protection level IP20
Packing units
Unit Type of Package 1 PCE
Number of Units in Package 1 1
Package 1 Height 164cm
Package 1 Width 111.4cm
Package 1 Length 68.3cm
Package 1 Weight 190kg
Contractual guarantee
maintainance 1 year on-site repair or replace with factory authorized Start-Up
