[最新產品] MSI 34" MAG 346CQ 180Hz 3440x1440 VA (21:9) 曲面電競顯示器 (MO-MA346CQ)

SPECIFICATIONS
Panel Size 34"
Active Display Area (mm) 797.22 (H) x 333.72 (V)
Curvature Curve 1500R
Panel Type VA
Panel Resolution 3440 x 1440 (UWQHD)
Pixel Pitch (H x V) 0.23175 (H) x 0.23175 (V)
Aspect Ratio 21:9
Brightness (nits) SDR: 300 cd/m²
Contrast Ratio 4000:1
DCR 100000000:1
Signal Frequency 71.040~268.200 KHz (H) / 48~180 Hz (V)
ACTIVATED RANGE 48~180Hz
Refresh Rate 180Hz
Response time 1ms (MPRT)
DYNAMIC REFRESH RATE
TECHNOLOGY Adaptive-Sync
HDR Support HDR Ready
Video ports 2x HDMI™ 2.0b (UWQHD@180Hz)
1x DisplayPort 1.4a (HBR3)
USB ports - N/A
Audio ports 1x Headphone-out
Viewing Angle 178° (H) / 178° (V)
Adobe RGB / DCI-P3 / sRGB 80% / 75% / 100% (CIE1976 Standard)
Surface Treatment Anti-glare
Display Colors 1.07b, 10 bits (8 bits + FRC)
SPEAKER - N/A
Console Mode
Supported Resolution & Refresh Rate:
1080p: 60Hz and 120Hz
1440p: 60Hz and 120Hz
HDMI™ CEC: Supported
VRR: PS5 and Xbox Supported
Frameless Design Yes
Power Type Internal Power Board
Power Input 100~240V, 50/60Hz
Adjustment (Tilt) -5°~20°
Adjustment (Swivel) - N/A
Adjustment (Pivot) - N/A
Adjustment (Height) - N/A
Kensington Lock Yes
VESA Mounting 100 x 100 mm
Dimension with Stand (W x D x H) 808 x 269.49 x 458.82 mm
(31.8 x 10.6 x 18 inch)
Dimension without Stand (W x D x
H)
808 x 111.93 x 363.92 mm
(31.8 x 4.4 x 14.3 inch)
Weight (NW / GW) 6.3 kg (13.8 lbs) / 8.52 kg (18.7 lbs)
Carton Dimension (W X D X H) 920 x 170 x 463 mm
(36.2 x 6.69 x 18.2 inch)
Accessories 1x DP Cable (1.4a), 1x Power Cord
(C13), 1x Quick Guide
Note
HDMI™: 3440 x 1440 (Up to 100Hz)
DisplayPort: 3440 x 1440 (Up to
180Hz)
Support: HDMI™ CEC, PIP/PBP; Non
Support: KVM

CONNECTIONS
1. 1. 5-Way Navigator
2. AC-in
3. 2x HDMI™ 2.0b
(UWQHD@100Hz)
4. DisplayPort 1.4a (HBR3)
5. Headphone-out
6. Kensington Lock

FEATURES
1500R Curved Gaming
Immerse in a captivating experience with a 1500R curvature rate.
180Hz High Refresh Rate
Experience smooth gaming with a blazing fast 180Hz refresh
rate, that gives you the upperhand in fast moving games.
1ms Fast Response Time
Eliminate screen tearing and choppy frame rates with 1ms(MPRT)
response time.
HDR Ready
Enhance eye-catching details through adjustments in contrast
and shadows.
AI Vision
Smart black tuner to brighten your day by bringing out the fine
details in dark areas.
