Description
Processor
AMD Ryzen™ 9 8945HX,16C/32T
Max Turbo Frequency 5.4 GHz
GPU
AMD Radeon™ 610M
Memory
DDR5 Up to 5200 MT/s (dual-channel)
Optional SKU DDR Capacity: 0 / 16 / 32 / 48 / 64 / 96 GB
Max Memory Capacity 96GB
Storage
2 × M.2 2280 NVMe SSD Slot
(up to 4TB) (PCIe 4.0 x4)
Optional SKU SSD Capacity: 0/512 GB/1 TB
Cooling System
Phase Change Material (PCM)
CPU Fan Type: Blower Fan
CPU Fan Speed: 4-pin/3500 RPM/12 V
Wireless Connectivity
Wi-Fi 7 & Bluetooth® 5.4
M.2 2230 E-Key Wi-Fi / Bluetooth Combo Module (PCIe Only)
Ethernet Controller
2.5GbE LAN (RJ45)
1 × RJ45 (Module: Realtek RTL8125)
Video Output
2 × HDMI 2.1 (up to 8K@60Hz / 4K@144Hz)
2 × DP 1.4 (up to 8K@60Hz / 4K@144Hz)
1 × DP 2.1 (up to 8K@60Hz / 4K@240Hz)
1 × USB Type-C (up to 4K@144Hz)
2 × HDMI 2.1 (up to 8K@60Hz / 4K@144Hz)
2 × DP 1.4 (up to 8K@60Hz / 4K@144Hz)
1 × DP 2.1 (up to 8K@60Hz / 4K@240Hz)
1 × USB Type-C (up to 4K@144Hz)
Audio Output
2 × HDMI 2.1
2 × DP 1.4
1 × DP 2.1
1 × Audio Out Port
1 × Line Out Port
2 × HDMI 2.1
2 × DP 1.4
1 × DP 2.1
1 × Audio Out Port
1 × Line Out Port
Dimensions
312 × 93 × 292 mm
