Description
- 強大的 WiFi 7 網狀網絡，憑藉高達 25000 Mbps 的超快四頻連接速度、多鏈路操作和 4096-QAM 技術，為您的智慧家庭提供面向未來的保障。
- 由 AI 驅動的 Ultimate AiMesh 提供強大的回程連接，覆蓋範圍高達 8,000 平方英尺（2 件裝），以及功能豐富的全屋網絡，可與任何 ASUS 可擴展路由器配合使用。
- 使用 Smart Home Master 可以輕鬆建立多達三個 SSID，從而簡化物聯網設備的設定和管理、實現即時 VPN 連接以及方便的家長控制。
- 十二個內建天線和十六個高功率前端模組消除了各個方向的 WiFi 盲區，而強大的散熱功能提高了 WiFi 的可靠性。
- 透過多樣化的廣域網路配置選項和方便的 USB 連接埠（支援 4G LTE 和 5G 行動網路共享），實現始終在線的互聯網連接。
- 使用由 Trend Micro™ 提供支援的商業級 AiProtection Pro，一鍵安全掃描，全面的 VPN 支援和網站到網站 VPN，確保安全無虞。
- 高級家長監護功能透過即時監控、便利的預設、可自訂的日程安排和獎勵設置，增強數位健康。
BQ16 (W-1-PK)
IPv6
IPv4
WiFi 7 (802.11be)
WiFi 6E (802.11ax)
WiFi 6 (802.11ax)
WiFi 5 (802.11ac)
WiFi 4 (802.11n)
IEEE 802.11g
IEEE 802.11b
IEEE 802.11a
BE25000 ultimate BE performance: 1376+5764+5764+11529 Mbps
WiFi 7 (802.11be) (6GHz): up to 11529 Mbps
WiFi 7 (802.11be) (5GHz-2): up to 5764 Mbps
WiFi 7 (802.11be) (5GHz-1): up to 5764 Mbps
WiFi 7 (802.11be) (2.4GHz): up to 1376 Mbps
Internal antenna x 12
6GHz 4x4
5GHz-2 4x4
5GHz-1 4x4
2.4GHz 4x4
RAM 2GB , Flash 256MB
OFDMA (Orthogonal Frequency Division Multiple Access)
Beamforming: standard-based and universal
4096-QAM high data rate
20/40/80/160/320 MHz bandwidth
2.4 GHz / 5 GHz / 6 GHz, 6 GHz
5 GHz-2
5 GHz-1
2.4 GHz
Access Point Mode
AiMesh Node Mode
Wireless Router Mode
10G WAN/LAN x 1, 10G LAN x 1, 1G WAN/LANx 1, 1G LAN x2, USB 3.0
Reset/ WPS/ Rocker Switch
Power x 1
AC Input : 110V~240V(50~60Hz)
DC Output : 19V with max. 3.42A current
ZenWiFi BQ16
RJ-45 cable
Power adapter
Warranty card
Quick start guide
1341g
214*174.2*72 mm
AiMesh, • Primary AiMesh Router, • AiMesh Node
"Allow you to block access to unwanted websites and apps.", Web & Apps Filters, Time Scheduling, Reward, Parental Control - Safe Browsing, Customized Internet Schedule, • Maximum Parental Control Profile : 64, • Maximum Parental Control Content Filter Rule : 64
APP: ASUS Router APP
"The Guest Network provides Internet connection for guests but restricts access to your local network.", Support Guest Network, • Maximum Guest Network Rule : 2.4G+5G/ 2.4G+5G+6G: 8, Guest Network Connection Time Limit, Open system, WPA/WPA2-Personal/WPA3-Personal
AiProtection, VPN, WPA3 Enterprise, WPA3 Personal, WPA2 Enterprise , WPA2 Personal, WPA Personal, WPA Enterprise , WPS support, WPS, Let's Encrypt, DNS-over-TLS, SSH, Security Scan, Firewall, • Maximum Firewall Keyword Filter : 64, • Maximum Firewall Network Service Filter : 32, • Maximum Firewall URL Filter : 64
AiProtection Pro, • Router Security Assessment, • Malicious Site Blocking, • Two-Way IPS, • Infected Device Prevention and Blocking
Instant Guard, VPN Client L2TP, VPN Client Open VPN, VPN Client PPTP, VPN Client WireGuard, VPN Server IPSec, VPN Server Open VPN, VPN Server PPTP, VPN Server WireGuard, VPN Fusion
Adaptive QoS, • Bandwidth Monitor, • Bandwidth Limiter, -- Maximum Bandwidth Limiter Rule : 32, Traditional QoS, Traffic Monitor, • Real-time Traffic Monitor, • Wired Traffic Monitor, • Wireless Traffic Monitor, Traffic Analyzer, • Traffic Analysis Period : Daily, Weekly, Monthly, • Website History
• Static IP
• Automatic IP
• L2TP
• PPTP
• PPPoE
Internet Connection Type, Dual WAN, 4G / 5G Auto Mobile Tethering, Port Forwarding, • Maximum Port Forwarding Rule : 64, Port Triggering, • Maximum Port Triggering Rule : 32, DMZ, DDNS
DHCP Server, IGMP Snooping, IPTV, LAN Link Aggregation, Manually Assign IP Address, Wake on LAN (WOL)
MU-MIMO, UTF-8 SSID, WiFi MAC Address Filter, • Maximum MAC Filters : 64, Wireless Scheduler, Airtime Fairness, Universal Beamforming, Explicit Beamforming
4G / 5G Auto Mobile Tethering, HDD Hibernation, AiCloud, Download Master, AiDisk, Media Server, Time Machine, Samba Server, FTP Server
Feedback System, System Log, New Device Connect Notification, Login Captcha, Connection Diagnosis, Auto Firmware Update
