Description
BD4(B-3-PK)
Network Standard
IPv6
IPv4
WiFi 7 (802.11be)
WiFi 6 (802.11ax)
WiFi 5 (802.11ac)
WiFi 4 (802.11n)
IEEE 802.11g
IEEE 802.11b
IEEE 802.11a
WiFi 7 (802.11be) (5GHz): up to 2882 Mbps
WiFi 7 (802.11be) (2.4GHz): up to 688 Mbps
Internal antennas x 4
5GHz 2x2
2.4GHz 2x2
1.5GHz quad-core processor
RAM 512MB , Flash 128MB
OFDMA (Orthogonal Frequency Division Multiple Access)
Beamforming: standard-based and universal
4096-QAM high data rate
20/40/80/160 MHz bandwidth
5 GHz
2.4 GHz
Access Point Mode
AiMesh Node Mode
Wireless Router Mode
2.5G x 2 (WAN/LAN auto detecting)
WPS button, Reset button, Power switch
Power x 1
AC Input : 110V~240V(50~60Hz)
DC Output : 12V with max 1.5A current
ZenWiFi BD4
RJ45 cable
Power adapter
Warranty card
Quick start guide
140 x 70 x 140 mm
Content may vary in different regions and packages.
AiMesh, Primary AiMesh router, AiMesh node
Parental Control, Web & Apps Filters, Time Scheduling, Reward, Parental Control - Safe Browsing, Parental Control Customized Internet schedule
ASUS Router APP
"The Guest Network provides Internet connection for guests but restricts access to your local network.", Guest Network
AiProtection, VPN, WPA/WPA2/WPA3-Personal, WPA/WPA2-Enterprise, WPS, Let's Encrypt, DNS-over-TLS, Security Scan, Firewall
AiProtection Pro, 有, Malicious site blocking, 有, Infected Device Prevention and Blocking
Instant Guard, VPN Client L2TP, VPN Client OVPN, VPN Client PPTP, VPN Client WireGuard, VPN Server IPSec, VPN Server OVPN, VPN Server PPTP, VPN Server WireGuard, VPN Fusion
有, Bandwidth Monitor, Bandwidth limiter, Traditional QoS, 有, 有, 有
Port forwarding, Port triggering, DMZ, DDNS
DHCP Server, IGMP snooping, IPTV, Manually assign IP address, Wake on LAN (WOL)
MU-MIMO, UTF-8 SSID, 有, 有, 有, 有, 有, 有
Diagnosis tools, Feedback system, System log, New Device Connect Notification, Login Captcha, Connection Diagnosis, Auto Firmware Update
Support Google Assistant
