Description
雙頻 WiFi 7 (802.11be) AiMesh 可擴充路由器，最高速度可達 3600 Mbps，覆蓋範圍高達 15,000 平方英尺*，配備雙 2.5G 端口，支援 PoE 供電，IP65 防護等級，支援壁掛桿式安裝，最多可設定 3 個網路供電，IP65 防護等級，支援壁掛式和桿式安裝，最多可設定 3 個網路供電，IP65 防護等級，支援壁掛式和桿式安裝，最多可設定 3 個設備網路和設備系統保護功能 支援和設備可保護功能最多 2 個網路系統。
- 雙頻 WiFi 7 速度高達 3600 Mbps，支援 MLO 和 4K-QAM。
- WiFi 7 為 AiMesh 技術提供支持，覆蓋範圍可達 15,000 平方英尺*，可輕鬆擴展，並與相容的華碩路由器在室內外實現無縫連接。
- 這款產品經久耐用，具有靜電放電和浪湧保護功能，IP65 認證的防水防塵外殼，以及 -30°C 至 60°C 的寬廣工作溫度範圍，使其成為戶外環境的理想之選。
- 支援乙太網路供電和交流電源供電，簡化了安裝選項，並具有兩個 2.5G PoE 輸入端口，支援自動 WAN 檢測。
- 多種安裝方式使其能夠輕鬆部署在各種戶外場景中，無論是壁掛式、桿式或平面。
- 利用商業級 AiProtection Pro 和高級 VPN 提供全天候端對端保護
- 使用智慧家庭主網絡，為物聯網設備和家長監護功能設定最多三個 SSID。
- 在一個開闊、無遮蔽的環境中
BD4 OUTDOOR (W-1-PK)
IPv6
IPv4
WiFi 7 (802.11be)
WiFi 6 (802.11ax)
WiFi 5 (802.11ac)
WiFi 4 (802.11n)
IEEE 802.11g
IEEE 802.11b
IEEE 802.11a
BE3600 ultimate BE performance : 688+2882 Mbps
WiFi 7 (802.11be) (5GHz): up to 2882 Mbps
WiFi 7 (802.11be) (2.4GHz): up to 688 Mbps
Internal antennas x 2
5GHz 2x2
2.4GHz 2x2
1.5GHz quad-core processor
RAM 512MB , Flash 128MB
OFDMA (Orthogonal Frequency Division Multiple Access)
Beamforming: standard-based and universal
4096-QAM high data rate
20/40/80/160 MHz bandwidth
5 GHz
2.4 GHz
Repeater Mode
Access Point Mode
AiMesh Node Mode
Wireless Router Mode
2.5G x 2 (WAN/LAN auto detecting)
Reset button
Power x 1
AC Input : 100V~240V(50~60Hz), 2A
ZenWiFi BD4 Outdoor
RJ45 cable
Power cord
Warranty card
Quick start guide
Mounting kit
1040
106 x 106 x 200
Content and coverage may vary in different region.
AiMesh, • Primary AiMesh Router, • AiMesh Node
"Allow you to block access to unwanted websites and apps.", Web & Apps Filters, Time Scheduling, Reward, Parental Control - Safe Browsing, Customized Internet Schedule
APP: ASUS Router APP
"The Guest Network provides Internet connection for guests but restricts access to your local network.", Support Guest Network
AiProtection, VPN, WPA/WPA2/WPA3-Personal, WPA/WPA2-Enterprise, WPS, Let's Encrypt, DNS-over-TLS, Security Scan, Firewall
AiProtection Pro, • Router Security Assessment, • Malicious Site Blocking, • Two-Way IPS, • Infected Device Prevention and Blocking
Instant Guard, VPN Client L2TP, VPN Client Open VPN, VPN Client PPTP, VPN Client WireGuard, VPN Server IPSec, VPN Server Open VPN, VPN Server PPTP, VPN Server WireGuard, VPN Fusion
Adaptive QoS, • Bandwidth Monitor, • Bandwidth Limiter, Traditional QoS, Traffic Monitor, Traffic Analyzer, • Website History
Port Forwarding, Port Triggering, DMZ, DDNS
DHCP Server, IGMP Snooping, IPTV, Manually Assign IP Address, Wake on LAN (WOL)
MU-MIMO, UTF-8 SSID, WiFi MAC Address Filter, Wireless Scheduler, Airtime Fairness, RADIUS Client, Universal Beamforming, Explicit Beamforming
Diagnosis Tools, Feedback System, System Log, New Device Connect Notification, Login Captcha, Connection Diagnosis, Auto Firmware Update
Support Google Assistant
