Specifications
Expansion slots
Vertical GPU: up to 4 slots (82mm); horizontal SFF GPU: 3 slots (63mm)
Front IO ports
1 x USB 3.1 Gen 2 Type-C, 2 x USB 3.0
2.5” drive max support
BVertical GPU: 4 x 2.5” SSD; horizontal SFF GPU: 8 x 2.5” SSD
Top and front panel
Two fine mesh panels
Front fan mounts
2 x 120/140 mm (not included)
Right side fan mounts
2 x 120/140 mm fans with 2.5 slot (52mm) GPU in 4 slots GPU mode
PCIe standard
PCIe Gen 4.0 x 16
Rear IO ports
Power Botton
3.5” drive max support
Vertical GPU: 2 x 3.5” HDD; horizontal SFF GPU: 4 x 3.5” HDD
Side panel
Two fine mesh panels
Top fan mounts
1 x 120 mm x 15 mm thick (not included)
Tool-less push-to-lock
Both side, top, and front panels
Compatibility
Motherboard compatibility
Mini-ITX, Mini-DTX, M-ATX, ATX
CPU cooler max height
3 slots GPU mode : max 74 mm height
4 slots GPU mode : max 54 mm height"
4 slots GPU mode : max 54 mm height"
GPU max length in ITX build
Vertical rear GPU in 4 slots (82mm):
332 mm length and 152 mm width;
353 mm length and 152 mm width with extra feet
Horizontal SFF GPU 3 slots (61 mm):
239 mm length and 160 mm width;
212 mm length and 160 mm width with front fan only
*GPU baffle not included in length and PCIe power connectors need 15-20 mm space"
332 mm length and 152 mm width;
353 mm length and 152 mm width with extra feet
Horizontal SFF GPU 3 slots (61 mm):
239 mm length and 160 mm width;
212 mm length and 160 mm width with front fan only
*GPU baffle not included in length and PCIe power connectors need 15-20 mm space"
Front radiator in ITX build
240/280 mm support max 332 mm length, 144 mm width, 63 mm thickness with fans
Right side radiator in ITX build
4 slots custom loop:
55 mm thickness of 240/280 mm radiator + fans allow GPU in 22 mm thick;
50 mm thickness of 240/280 mm radiator + fans allow GPU in 27 mm thick;
45 mm thickness of 240/280 mm radiator + fans allow GPU in 32 mm thick;
45 mm thickness of 240/280 mm radiator + fans allow GPU in 32 mm thick
55 mm thickness of 240/280 mm radiator + fans allow GPU in 22 mm thick;
50 mm thickness of 240/280 mm radiator + fans allow GPU in 27 mm thick;
45 mm thickness of 240/280 mm radiator + fans allow GPU in 32 mm thick;
45 mm thickness of 240/280 mm radiator + fans allow GPU in 32 mm thick
Power supply type
SFX, SFX-L, ATX
PSU max length
170 mm ATX PSU with front fan only;
160 mm ATX PSU with upward tubing AIO;
150 mm ATX PSU with downward tubing AIO"
160 mm ATX PSU with upward tubing AIO;
150 mm ATX PSU with downward tubing AIO"
GPU max length in ATX/MATX build
Vertical front GPU in 3 slots (62 mm):
314 mm length and 120 mm width;
325 mm length and 120 mm width with extra feet
Vertical front GPU in 2.8 slots (57mm):
314 mm length and 124 mm width;
335 mm length and 124 mm width with extra feet
Vertical rear GPU in 3 slots (63mm):
332 mm length and 152 mm width;
353 mm length and 152 mm width with extra feet
*GPU baffle not included in length and PCIe power connectors need 15-20 mm space
314 mm length and 120 mm width;
325 mm length and 120 mm width with extra feet
Vertical front GPU in 2.8 slots (57mm):
314 mm length and 124 mm width;
335 mm length and 124 mm width with extra feet
Vertical rear GPU in 3 slots (63mm):
332 mm length and 152 mm width;
353 mm length and 152 mm width with extra feet
*GPU baffle not included in length and PCIe power connectors need 15-20 mm space
Right side radiator in ATX/MATX build
240 mm support max 120 mm width, 53 mm thickness with fans
General
Case dimensions (L x W x H)
247 mm x 167 mm x 362 mm / 9.72 inch x 6.57 inch x 14.25 inch
Net weigh
3.2 kg / 7.05 lb
Volume
14.93 liters
Package contents
Meshroom S, accessory box included screws and parts, user manual, PCIe cable, monitor connecting cable
Package dimensions (L x W x H)
415 mm x 220 mm x 310 mm / 16.34 inch x 8.66 inch x 12.2 inch
Gross weight
3.75 kg / 8.27 lb
Case material
SGCC powder coated steel, plastic
Warranty
1 year on case, PCIe riser cable, monitor connecting cable, pc case parts, and front / rear IO ports
