| SPECIFICATIONS |
| Brand |
Seagate |
| Series |
IronWolf Pro |
| Model |
ST4000NE001 |
| Interface |
SATA 6Gb/s |
| Capacity |
4 TB |
| Form Factor |
3.5" |
| Features and Performance |
| Drive Bays Supported |
Up to 24-bay |
| Multi-User Technology |
300 TB/Year |
| Rotational Vibration (RV) Sensor |
Yes |
| Hot-Plug Support |
Yes |
| Cache (MB) |
256MB |
| Reliability/Data Integrity |
| Mean Time Between Failures (MTBF, Hours) |
1,200,000 |
| Reliability Rating @ Full 24×7 Operation (AFR) |
0.73% |
| Non-Recoverable Read Errors per Bits Read, Max |
1 per 10E15 |
| Power-On Hours per Year (24×7) |
8,760 |
| Sector Size (Bytes per Logical Sector) |
512E |
| Rescue Services |
Yes |
| Performance |
| Spindle Speed (RPM) |
7,200 |
| Interface Access Speed (Gb/s) |
6.0, 3.0, 1.5 |
| Max. Sustained Transfer Rate OD (MB/s) |
214MB/s |
| Average Latency (ms) |
4.16 |
| Interface Ports |
Single |
| Rotational Vibration @ 10-1,500 Hz (rad/s) |
12.5 |
| Power Management |
| Startup Current, Typical (12V, A) |
2 |
| Idling Average (W) |
5.5 W |
| Average Operating Power (W) |
8.7W |
| Standby Mode/Sleep Mode, Typical (W) |
1/1 |
| Power Supply Requirements |
+12 V and +5 V |
| General |
| Operating Temperature Range |
5°C - 60°C |
| Non-Operating Temperature Range |
-40°C - 70°C |
| Shock, Operating 2 ms (Read/Write) (Gs) |
50/50 Gs |
| Shock, Non-Operating, 1 ms and 2 ms (Gs) |
200 Gs |
| Dimension |
26.11 x 101.85 x 147 mm |
| Weight |
643 g |
| Warranty Information |
| Warranty |
5 Year Limited Warranty |
