| SPECIFICATIONS |
| Brand |
Seagate |
| Series |
Skyhawk AI |
| Model |
ST16000VE002 |
| Capacity |
16TB |
| Interface |
SATA 6 Gb/s |
| Recording Technology |
CMR |
| Drive Design |
Helium |
| Features & Performance |
| Drive Bays Supported |
16+ |
| AI Channels |
32 |
| AI Real Time Capture Events/Sec |
Up to 120 |
| AI Real Time Compare Events/Sec |
Up to 96 |
| HD Cameras Supported |
Up to 64 |
| RV Sensors |
Yes |
| Max. Sustained Transfer Rate OD |
250MB/s |
| Cache |
256MB |
| Reliability / Data Integrity |
| Tarnish Resistant |
Yes |
| Load / Unload Cycles |
300,000 |
| Non-recoverable Read Errors Rate |
1 per 10E15 |
| Power-On Hours per Year |
8760 |
| Workload Rate Limit (WRL) |
550 |
| Mean Time Between Failures (MTBF) |
2,000,000 Hours |
| Power Management |
| Startup Current, Typical (12V) |
1.8A |
| Average Operating Power |
6.71W |
| Idling Average |
5.1W |
| Standby Mode/Sleep Mode, Typical |
1.05/1.05 |
| Voltage Tolerance (5 V) |
5% |
| Voltage Tolerance (12 V) |
10% |
| Environmental / Temperature |
| Operating |
5°C -70°C |
| Physical |
| Dimensions |
26.11mm x 101.85mm x 146.99mm |
| Weight |
670g |
| Warranty Information |
| Warranty |
3 Year Warranty |
