| SPECIFICATIONS |
| Brand |
Seagate |
| Series |
SkyHawk AI Surveillance |
| Model |
ST10000VE001 |
| Capacity |
10TB |
| Interface |
SATA 6 Gb/s |
| Drive Design |
Air |
| Recording Technology |
CMR |
| Features and Performance |
| Drive Bays Supported |
16+ |
| AI Channels |
32 |
| AI Real Time Capture Events/Sec |
Up to 120 |
| AI Real Time Compare Events/Sec |
Up to 96 |
| HD Cameras Supported |
Up to 64 |
| RV Sensors |
Yes |
| Max. Sustained Transfer Rate OD |
245MB/s |
| Cache |
256 MB |
| Reliability/Data Integrity |
| Tarnish Resistant |
Yes |
| Load/Unload Cycles |
600,000 |
| Non-recoverable Read Errors Rate, Max |
1 per 10E15 |
| Power-On Hours per year |
8,760 |
| Workload Rate Limit (WRL) |
550 |
| Mean Time Between Failures (MTBF) |
2,000,000 Hrs |
| Rescue Data Recovery Services |
3 Years |
| Power Management |
| Startup Current, Typical (12V, A) |
2 |
| Average Operating Power |
10.1 W |
| Idling Average |
7.8 W |
| Standby Mode/Sleep Mode, Typical (W) |
1/1 |
| Voltage Tolerance (5V) |
±5% |
| Voltage Tolerance (12V) |
±10% |
| Environmental |
| Operating Temperature (Ambient, min) |
0°C |
| Operating (drive reported, max) |
65°C |
| Non-operating (ambient, min) |
-40°C |
| General |
| Product Dimensions |
26.11 x 101.85 x 146.99 mm |
| Product Weight |
0.720 g |
| Warranty Information |
| Warranty |
3 Year Limited Warranty |
