FAN Specification
Size
120x120x25 mm
Mounting hole spacing
105x105 mm
4-pin PWM
Cable length
40cm
Bearing
Blade geometry
Heptaperf™
Frame technology
Material
Fibre-glass reinforced polyamide
Ingress protection
IP52
Motor type
Rotational speed (+/- 10%)
3000 RPM
Min. rotational speed @ 20% PWM (+/-20%)
750 RPM
Acoustical noise
43,5 dB(A)
Static pressure
7,63 mm H₂O
Input power (typical)
3,17 W
Input power (max.)
3,6 W
Input current (typical)
0,26 A
Max. input current
0,3 A
Operating voltage
12 V
MTTF
> 150.000 h
Scope of delivery
- Fan
- 4 Fan Screws
6 years
