FAN Specification
Size
40x40x10 mm
Mounting hole spacing
32x32 mm
Cable length
20cm + 30cm NA-EC1 extension cable
Bearing
Blade geometry
A-Series with Flow Acceleration Channels
Frame technology
Rotational speed (+/- 10%)
4500 RPM
Rotational speed with L.N.A. (+/- 10%)
3700 RPM
Acoustical noise
17,9 dB(A)
Acoustical noise with L.N.A.
12,9 dB(A)
Static pressure
1,78 mm H₂O
Static pressure with L.N.A.
1,21 mm H₂O
Input power (typical)
0,264 W
Input power (max.)
0,6 W
Input current (typical)
0,022 A
Max. input current
0,05 A
Operating voltage
12 V
MTTF
> 150.000 h
Scope of delivery
- Low-Noise Adaptor (L.N.A.)
- 3:2 Pin Adaptor
- OmniJoin Adaptor Set
- 30cm Extension Cable
- 4 Vibration-Compensators
- 4 Fan Screws
6 years
