描述
| Model Name | TEN | ||||
| Mode | M1 | M2 | I3 | ||
| Color | Black / White | Black / White | Black / White | ||
| Dimensions (L*W*H) | 420*185*293mm (22.7L / Main Frame) 442*196.5*326.05mm (28.3L / Excl. Protrusions) 456*196.5*327.65mm (29.3L / Incl. Protrusions) 505*260*395mm (Carton) |
420*185*293mm (22.7L / Main Frame) 442*196.5*326.05mm (28.3L / Excl. Protrusions) 456*196.5*327.65mm (29.3L / Incl. Protrusions) 505*260*395mm (Carton) |
420*185*293mm (22.7L / Main Frame) 442*196.5*326.05mm (28.3L / Excl. Protrusions) 456*196.5*327.65mm (29.3L / Incl. Protrusions) 505*260*395mm (Carton) |
||
| MB Support | Micro-ATX / Mini-ITX | Micro-ATX / Mini-ITX | Mini-ITX | ||
| Front I/O | Power Button*1 / USB3.0*2 / Type-C (20G)*1 / Headset Audio Jack*1 | Power Button*1 / USB3.0*2 / Type-C (20G)*1 / Headset Audio Jack*1 | Power Button*1 / USB3.0*2 / Type-C (20G)*1 / Headset Audio Jack*1 | ||
| PCIe Slots | Horizontal | 4 | 4 | 4 | |
| Vertical | 3 | 3 | 3 | ||
| Compatibility / Maximum | CPU Cooler | 155mm | 155mm | 52mm | |
| GPU | Horizontal | 425mm | 410mm | 410mm | |
| Vertical | 410mm | 410mm | 410mm | ||
| PSU | ATX / SFX-L / SFX (Front / MB Bracket) | ATX / SFX-L / SFX (Front / MB Bracket) | SFX-L / SFX (MB Bracket) | ||
| Drive Support / Maximum | 3.5” HDD | 2 | 2 | - | |
| 2.5” SSD | 4 | 4 | 3 | ||
| Pre-installed Fan (s) | Rear | 92mm*1 | 92mm*1 | 92mm*1 | |
| Fan Support | Top | 120mm*3 / 140mm*2 | 120mm*3 / 140mm*2 | 120mm*3 / 140mm*2 | |
| Side | 120mm*3 / 140mm*2 | 120mm*3 / 140mm*2 | 120mm*3 / 140mm*2 | ||
| Bottom | 120mm*3 / 140mm*2 | 120mm*3 / 140mm*2 | 120mm*3 / 140mm*2 (Depends on GPU Size) | ||
| Rear | 92mm*1 | 92mm*1 | 92mm*1 | ||
| Radiator Support | Top | - | 120 / 140 / 240 / 280 / 360mm (Vertical GPU) | 120 / 140 / 240 / 280 / 360mm (Vertical GPU) | |
| Side | 120 / 140 / 240 / 280 / 360mm (Horizontal GPU) | 120 / 140 / 240 / 280 / 360mm (Horizontal GPU) | 120 / 140 / 240 / 280 / 360mm (Horizontal GPU) | ||
| Bottom | 120 / 140 / 240 / 280 / 360mm (Vertical GPU) | - | - | ||
| Dust Filter | Bottom | Bottom | Bottom | ||
| EAN | 4710562742473 / 4710562746570 | 4710562742473 / 4710562746570 | 4710562742473 / 4710562746570 | ||
| Warranty | 1 Year | 1 Year | 1 Year | ||
