描述
| Model | MS-A2 |
| CPU | AMD Ryzen™ 7 7745HX |
| GPU | AMD Radeon™ 610M |
| Memory | Dual channel DDR5, SODIMM x 2 (max. 96GB) Pre-install : 32GB (5200 MHz) |
| Storage | 1 x M.2 2280/U.2NVME SSD (Up to 15TB)(PCIe 4.0x4) 2 x M.2 2280/22110NVME/SATA SSD (Up to 4TB)(PCIe 4.0x4) Pre-installed : 1TB SSD |
| Wireless Connectivity | M.2 2230 E-Key (Wi-Fi 6E & Bluetooth® 5.2) |
| Video Output | HDMI (2.1) x 1 (Up to 8K@60Hz) USB Type-C x 1 (Up to 8K@60Hz/4K@144Hz)(Alt DP 2.0) |
| Audio Output | HDMI x 1 3.5mm Combo Jack 4-in-1 х 1 |
| Audio Input | 3.5mm Combo Jack 4-in-1 х 1 |
| I/O Ports | HDMI (2.1) x 1 USB Type-C x 2 USB 3.2 Gen 2 Type-A x 1 (10 Gbps) USB 3.2 Gen 1 Type-A x 3 (5 Gbps) USB 2.0 x 1 10 Gb SFP+ Ethernet Port x 2 (Intel X710) 2.5Gb Ethernet Port x 1 (Realtek RTL8125) 2.5Gb Ethernet Port x 1 (Intel 1226-V) 3.5mm Audio Combo Jack x 1 |
| Button | - Power Button With LED(White) х 1 - Reset Hole x 1 |
| PCIe Expansion | PCIe x16 (PCIe 4.0 x8) |
| Fan | - Fan for CPU (12V) - Fan for SSD (5V) |
| Power Adapter | DC19V, 12.63A (240W) |
|
Operating System |
None |
|
Dimensions |
196 x 189 x 48 mm |
