LIAN LI UNI FAN SL120 V2 Reverse Blade White 白色 12CM Case Fan (UF-RSL120V2-1W)


價格:
特價$220.00

描述

SPECIFICATIONS

PRODUCT NAME UNI FAN SL V2 120 Reversed Blade
MODEL
RSL120V2-1W
COLOR
White
NUMBER OF FANS 1
CONTROLLER No
CONNECTOR TYPE 1 × 4-PIN PWM + 3-PIN ARGB
MATERIAL PBT/PC/Aluminum
FAN DIMENSION 120 X 120 X 28 (mm)
RATED VOLTAGE DC 12V (FAN) & 5V (LED)
FAN SPEED 0, 250~2000 RPM
MAX. AIR PRESSURE 2.19 mmH2O (Maximum)
MAX. AIRFLOW 65.4 CFM (Maximum)
ACOUSTIC NOISE 32 dB(A) Max
LOCKED CURRENT 0(Automatic Protection)
BEARING TYPE Fluid Dynamic Bearing (FDB)
OPERATE VOLTAGE DC12V & 5V
START-UP VOLTAGE ≦5 V
INPUT POWER 0.17A
INPUT POWER 2.04W
WARRANTY 2 years

White


CONSISTENT APPEARANCE

View the fan front way no matter intake or exhaust way.


UPGRADED MODULARITY

UNI FAN SL V2 reverse blade features an interlocking system to connect up to 6 fans in two clusters to a single controller port, making fans installation and cable management a simple job.

PLUG-IN POWER CABLE MODULE
Flush with fan frame, reduces clearance issues.


SLIDE-IN MECHANISM
Pin-to-pad contact, daisy-chaining the fan into a simple cluster.


REMOVABLE KEY
Remove the interlocking key to improve compatibility.


SINGLE CABLE TO CONTROLLER
(INCLUDED IN 3 PACK UNI FAN SL120-V2)
Combines fan power and LED signal into one cable, reduces cable clutter.


EXTENSION CABLE
(INCLUDED IN 3 PACK UNI FAN SL120-V2)
Bridges 2 fan clusters for a minimalistic cable solution.



UNCOMPROMISED PERFORMANCE

The UNI FAN SLV2 reverse blade operates with a slightly higher noise level with a better airflow compared to the original UNI FAN SLV2.

AIRFLOW

65.4 CFM

STATIC PRESSURE

2.19 mmH2O

NOISE

32 dBA

SPEED

0, 250-2000 RPM


1.

REVERSED BLADE
Blade in the other way around

2.

MAGNETIC FRAME
To provide extra support for fan blades

3.

MAGNETIC RUBBER RING
To ensure extreme stability

4.

FLUID DYNAMIC BEARING (FDB)
To effectively reduce the internal friction for improved durability

5.

CIRCLIP
To secure the fan blades in place

6.

STATOR
To provide a rotating magnetic field that generates momentum

7.

EXTRA MAGNETIC FORCE
To support the fan blades and reduce vibration levels, thus ensuring a low noise level while in operation

8.

RUBBER PADS
To reduce vibrations and ensure extremely low noise levels



SOPHISTICATED LIGHTING DESIGN

DETAIL ORIENTED

The cut edge of the rubber pads is designed to create a smoother curve along the light diffuser.

CONTINUOUS LED CHANNEL

The light gap between the two fans when interlocked together has been reduced from 5.6mm to 3mm, sketching out the elegant lighting effects.



L-CONNECT 3 SOFTWARE TO CONTROL UNI FAN SL V2 REVERSE BLADE FANS

Control and preview with precision the lighting effect of the UNI FAN SL V2 reverse blade fans with the new L-Connect interface.


Note: Only available when connecting via a UNI FAN SL-V2 controller, controller is sold separately or included in triple pack regular fan.

1.

Select lighting effects or set as merge mode

2.

Set personalized color / brightness / speed / direction



PACKAGE CONTENT


SL120V2-R Single Pack

White
