InWin A5 Black 黑色 Tempered Glass ATX Case IW-CS-A5BLK-1AM120S



Product number IW-CS-A5BLK-1AM120S
Color Black
Chassis type Mid-tower chassis
Material SECC galvanized steel, tempered glass, ABS, PC
Motherboard compatible 12" x 11" E-ATX, ATX, Micro-ATX, Mini-ITX
Interface card expansion slot 7 x PCI-E
Highest compatibility Supports high-specification graphics card length: 340 mm
Supports CPU radiator height: 162 mm
Front output/input port 1 x USB 3.2 Gen 2x2 Type-C
2 x USB 3.2 Gen 1
HD Audio Combo (CTIA standard universal headphone jack)
Hidden disk slot 2 x 3.5" / 2.5"
2 x 2.5"
Cooling system compatible Fans:
Top: 2 x 120 mm
Rear: 1 x 120 mm
Bottom: 2 x 120 mm
(1 Mercury AM120S fan is standard)

Water cooling radiator:
Top: 1 x 240 mm
Power supply compatible PSII: ATX12V
length must be between 140 - 200 mm
(*If the power supply exceeds 170 mm, only graphics cards shorter than 280 mm can be used)
Product dimensions
(length x width x height)
399 x 215 x 407 mm
Packaging size
(length x width x height)
473 x 277 x 483 mm
net weight 5.86 kg
gross weight 6.94 kg
