描述
ASUS ProArt Display OLED PA32DC 專業顯示器 – 31.5 吋、OLED、4K UHD (3840 x 2160)、99% DCI-P3、內建自動翻轉色度計、自我 / 自動校色、 Dolby Vision、HDR-10、HLG、ΔE < 1、USB-C、HDMI、硬體校準、Calman Ready、ColourSpace 整合
- 31.5 吋 4K (3840 x 2160) HDR OLED 面板具備 RGB 燈條和 99% DCI-P3 色域
- 內建自動翻轉色度計支援自我 / 自動校色，並相容Calman和Light Illusion ColourSpace CMS專業硬體校色軟體
- 真 10 位元色彩深度和 1,000,000:1 對比度提供最深邃的黑色和準確的高光
- 支援多種 HDR 格式，包括Dolby Vision®、HDR10 和 HLG
- 包含兩個多功能支架選項以適應任何場景或使用環境，並配備雅緻的金屬把手以便攜帶
- 顯示器罩有助於減少反光，隨附的固定夾可供輕鬆整理纜線
----------------------------------------------------------------------------------------------
Display
Panel Size (inch) : 31.5
Pixels Per Inch (PPI) : 140
Aspect Ratio : 16:9
Display Viewing Area (H x V) : 697.92 x 392.58 mm
Display Surface : Non-Glare
Panel Type : OLED
Viewing Angle (CR≧10, H/V) : 178°/ 178°
Pixel Pitch : 0.182mm
Resolution : 3840x2160
Color Space (Adobe RGB) : 99%
Color Space (DCI-P3) : 99%
Brightness (HDR, Peak) : 500 cd/㎡
Brightness (Typ.) : 250cd/㎡
Contrast Ratio (HDR, Max) : 100,000,000:1
Contrast Ratio (Typ.) : 1,000,000:1
Display Colors : 16.7M
Response Time : 0.1ms(GTG)
HDR (High Dynamic Range) Support : HDR10
HDR (High Dynamic Range) Support : HLG
HDR (High Dynamic Range) Support : Dolby Vision
Flicker-free : Yes
Pixels Per Inch (PPI) : 140
Aspect Ratio : 16:9
Display Viewing Area (H x V) : 697.92 x 392.58 mm
Display Surface : Non-Glare
Panel Type : OLED
Viewing Angle (CR≧10, H/V) : 178°/ 178°
Pixel Pitch : 0.182mm
Resolution : 3840x2160
Color Space (Adobe RGB) : 99%
Color Space (DCI-P3) : 99%
Brightness (HDR, Peak) : 500 cd/㎡
Brightness (Typ.) : 250cd/㎡
Contrast Ratio (HDR, Max) : 100,000,000:1
Contrast Ratio (Typ.) : 1,000,000:1
Display Colors : 16.7M
Response Time : 0.1ms(GTG)
HDR (High Dynamic Range) Support : HDR10
HDR (High Dynamic Range) Support : HLG
HDR (High Dynamic Range) Support : Dolby Vision
Flicker-free : Yes
Video Feature
ProArt Preset : Standard
ProArt Preset : sRGB
ProArt Preset : Adobe RGB
ProArt Preset : DCI-P3
ProArt Preset : Rec. 2020
ProArt Preset : DICOM
ProArt Preset : Rec. 709
ProArt Preset : HDR_PQ DCI
ProArt Preset : HDR_PQ Rec2020
ProArt Preset : HDR_HLG
ProArt Preset : HDR_HLG DCI
ProArt Preset : Dolby Vision
ProArt Preset : User mode1
ProArt Preset : User mode2
SPLENDID Technology : 有
Color Temp. Selection : Yes(5 modes)
Color Adjustment : 6-axis adjustment(R,G,B,C,M,Y)
Gamma Adjustment : Yes (Support Gamma 1.8/2.0/2.2/2.4/2.6 )
Color Accuracy : △E< 1
ASUS ProArt Hardware Calibration : Yes
ProArt Palette : Yes
QuickFit Plus : Yes
PIP / PBP Technology : Yes
HDCP : Yes
HDR Preview : Yes
ProArt Chroma Tune : Yes
Low Blue Light : Yes
ProArt Preset : sRGB
ProArt Preset : Adobe RGB
ProArt Preset : DCI-P3
ProArt Preset : Rec. 2020
ProArt Preset : DICOM
ProArt Preset : Rec. 709
ProArt Preset : HDR_PQ DCI
ProArt Preset : HDR_PQ Rec2020
ProArt Preset : HDR_HLG
ProArt Preset : HDR_HLG DCI
ProArt Preset : Dolby Vision
ProArt Preset : User mode1
ProArt Preset : User mode2
SPLENDID Technology : 有
Color Temp. Selection : Yes(5 modes)
Color Adjustment : 6-axis adjustment(R,G,B,C,M,Y)
Gamma Adjustment : Yes (Support Gamma 1.8/2.0/2.2/2.4/2.6 )
Color Accuracy : △E< 1
ASUS ProArt Hardware Calibration : Yes
ProArt Palette : Yes
QuickFit Plus : Yes
PIP / PBP Technology : Yes
HDCP : Yes
HDR Preview : Yes
ProArt Chroma Tune : Yes
Low Blue Light : Yes
Audio Feature
Speaker : Yes(3Wx2)
I/O Ports
USB-C x 1
DisplayPort 1.4 x 1
HDMI(v2.0) x 3
USB Hub : 4x USB 3.2 Gen 2 Type-A
Earphone Jack : Yes
PC Audio Input : Yes
USB-C Power Delivery : 65W
DisplayPort 1.4 x 1
HDMI(v2.0) x 3
USB Hub : 4x USB 3.2 Gen 2 Type-A
Earphone Jack : Yes
PC Audio Input : Yes
USB-C Power Delivery : 65W
Signal Frequency
Digital Signal Frequency : 31~135 KHz (H) / 24~75 Hz (V)
Power Consumption
Power Consumption : <38W
Power Saving Mode : <0.5W
Power Off Mode : 0W (hard switch)
Voltage : 100-240V, 50/60Hz
Power Saving Mode : <0.5W
Power Off Mode : 0W (hard switch)
Voltage : 100-240V, 50/60Hz
Mechanical Design
Tilt : Yes (+23° ~ -5°)
Swivel : Yes (+30° ~ -30°)
Pivot : Yes (+90° ~ -90°)
Height Adjustment : 0~130mm
Ambient Light Sensor : Yes
VESA Wall Mounting : 100x100mm
Kensington Lock : Yes
Swivel : Yes (+30° ~ -30°)
Pivot : Yes (+90° ~ -90°)
Height Adjustment : 0~130mm
Ambient Light Sensor : Yes
VESA Wall Mounting : 100x100mm
Kensington Lock : Yes
Dimensions (Esti.)
Phys. Dimension with Stand (W x H x D) : Mini Stand : 735.4 x 489.1 x 162.6 mm / Standard Stand: 735.4 x (496.9~626.9) x 245.0 mm
Phys. Dimension without Stand (W x H x D) : 735.4 x 466.9 x 54.4 mm
Box Dimension (W x H x D) : 878 x 616 x 298 mm
Phys. Dimension without Stand (W x H x D) : 735.4 x 466.9 x 54.4 mm
Box Dimension (W x H x D) : 878 x 616 x 298 mm
Weight (Esti.)
Net Weight with Stand : Mini Stand : 8 Kg / Standard Stand: 12.14 Kg
Net Weight without Stand : 7.6 Kg
Gross Weight : 20.35 Kg
Net Weight without Stand : 7.6 Kg
Gross Weight : 20.35 Kg
Accessories (vary by regions)
Cable Clip
Color pre-calibration report
DisplayPort cable
Ergonomic Stand
HDMI cable
L-shaped Screwdriver
Monitor hood
Power cord
Quick start guide
USB-C cable
USB-C to A cable
Warranty Card
Color pre-calibration report
DisplayPort cable
Ergonomic Stand
HDMI cable
L-shaped Screwdriver
Monitor hood
Power cord
Quick start guide
USB-C cable
USB-C to A cable
Warranty Card
Certificate
Energy Star
TÜV Flicker-free
TÜV Low Blue Light
VESA DisplayHDR 400 True Black
Calman Ready
TÜV Flicker-free
TÜV Low Blue Light
VESA DisplayHDR 400 True Black
Calman Ready
