model
ASUS ZenScreen MB169CK
screen
Panel size (inch): 15.6Aspect
ratio: 16:
9Display size (horizontal x vertical): 344.16 x 193.59mmDisplay
panel: Anti-GlareBacklight
type: LEDPanel
type: IPSViewing
angle (CR≧10, H/V): 178°/ 178°
Pixel pitch: 0.179mmResolution
: 1920x1080Brightness
(Typ): 250cd/㎡Contrast
ratio (Typ.): 800:1Display
color: 262KResponse
time: 5ms (GTG)
Frame refresh rate (max): 60HzFlicker
-free technology: Yes
ratio: 16:
9Display size (horizontal x vertical): 344.16 x 193.59mmDisplay
panel: Anti-GlareBacklight
type: LEDPanel
type: IPSViewing
angle (CR≧10, H/V): 178°/ 178°
Pixel pitch: 0.179mmResolution
: 1920x1080Brightness
(Typ): 250cd/㎡Contrast
ratio (Typ.): 800:1Display
color: 262KResponse
time: 5ms (GTG)
Frame refresh rate (max): 60HzFlicker
-free technology: Yes
Image Features
Trace Free Technology: Yes
SPLENDID Image Preset Mode: Yes
Color Temperature Selection: Yes (4 modes)
GamePlus:
QuickFit Support (Mode): Support (Photo/Alighment Grid)
HDCP Support: Support, 1.4
Low Blue Light Mode: Yes
SPLENDID Image Preset Mode: Yes
Color Temperature Selection: Yes (4 modes)
GamePlus:
QuickFit Support (Mode): Support (Photo/Alighment Grid)
HDCP Support: Support, 1.4
Low Blue Light Mode: Yes
Sound characteristics
Speaker: No
I/O Ports
USB-CUSB-C x 2
Mini HDMI x 1
Mini HDMI x 1
Signal frequency
Digital signal frequency: USB-C: 24~83KHZ (H) / 50~60Hz(V)
HDMI: 24~83KHZ (H) / 50~60Hz(V)
HDMI: 24~83KHZ (H) / 50~60Hz(V)
power consumption
Power on (Typical): 7.64 W
Power saving mode: <0.5 W
Power off mode: <0.3 W
Voltage: 100-240V, 50/60Hz
Power saving mode: <0.5 W
Power off mode: <0.3 W
Voltage: 100-240V, 50/60Hz
Mechanism Design
Height Adjustment: No
1/4" Tripod Socket: Tripod Socket: Supported
1/4" Tripod Socket: Tripod Socket: Supported
Product size (estimated)
Physical dimensions without base (W x H x D): 36.0 x 22.6 x 1.2 cm (14.17" x 8.90" x 0.47")
Carton dimensions (W x H x D): 43.4 x 29.0 x 7.6 cm (17.09" x 11.42" x 2.99")
Carton dimensions (W x H x D): 43.4 x 29.0 x 7.6 cm (17.09" x 11.42" x 2.99")
Weight (estimated)
Net weight without stand: 0.78 kg (1.72 lbs)
Gross weight: 1.70 kg (3.75 lbs)
Gross weight: 1.70 kg (3.75 lbs)
Accessories
360° kickstand
Mini HDMI to HDMI cable Power
adapter (optional)
Quick Start Guide
USB Type-C cable Warranty
card
ZenScreen sleeve
Mini HDMI to HDMI cable Power
adapter (optional)
Quick Start Guide
USB Type-C cable Warranty
card
ZenScreen sleeve
Certification
Energy Star
TÜV Flicker-free
TÜV Low Blue Light Certification
FSC MIX
TÜV Flicker-free
TÜV Low Blue Light Certification
FSC MIX
Remark
*Box dimension may vary from regions
