描述
ASUS ZenScreen Touch MB16AHT portable monitor — 15.6-inch FHD (1920 x 1080), IPS, 10-point touch, Mini-HDMI, ergo kickstand, tripod socket, ASUS Flicker Free and Low Blue Light technologies
- 15.6-inch IPS portable monitor with 10-point touch support
- Responsive and intuitive input with 10-point touch functionality supports high-productivity multitasking
- Two USB-C® (DP Alt mode) and mini HDMI® ports provide versatile connectivity with PC, laptops or game consoles.
- Integrated kickstand offers both landscape and portrait orientation to suit different scenarios
- Built-in ¼”-threaded socket for compatibility with a standard tripod
型號
ZenScreen Touch MB16AHT
Display
Aspect Ratio : 16:9
Display Viewing Area (H x V) : 344.16 x 193.59 mm
Display Surface : Non-Glare
Backlight Type : LED
Panel Type : IPS
Viewing Angle (CR≧10, H/V) : 170°/ 170°
Resolution : 1920x1080
Brightness (Typ.) : 250cd/㎡
Display Colors : 262K
Response Time : 5ms(GTG)
Touch : Yes (PCAP Touch)
Flicker-free : Yes
Display Viewing Area (H x V) : 344.16 x 193.59 mm
Display Surface : Non-Glare
Backlight Type : LED
Panel Type : IPS
Viewing Angle (CR≧10, H/V) : 170°/ 170°
Resolution : 1920x1080
Brightness (Typ.) : 250cd/㎡
Display Colors : 262K
Response Time : 5ms(GTG)
Touch : Yes (PCAP Touch)
Flicker-free : Yes
Video Feature
Trace Free Technology : Yes
SPLENDID Technology : Yes
Color Temp. Selection : Yes(4 modes)
GamePlus : Yes
QuickFit : Yes (Photo/Alighment Grid)
HDCP : Yes, 1.4
DisplayWidget : Yes, DisplayWidget Lite
Low Blue Light : Yes
SPLENDID Technology : Yes
Color Temp. Selection : Yes(4 modes)
GamePlus : Yes
QuickFit : Yes (Photo/Alighment Grid)
HDCP : Yes, 1.4
DisplayWidget : Yes, DisplayWidget Lite
Low Blue Light : Yes
Audio Feature
Speaker : Yes(1Wx2)
I/O Ports
USB-C x 2 (DP Alt Mode)
Mini HDMI x 1
Earphone Jack : Yes
Mini HDMI x 1
Earphone Jack : Yes
Signal Frequency
Digital Signal Frequency : HDMI: 24~83 KHz (H) / 50~61 Hz (V)
USB-C: 83 KHz (H) / 50~61 Hz (V)
USB-C: 83 KHz (H) / 50~61 Hz (V)
Power Consumption
Power Consumption : 9.88 W
Power Saving Mode : <0.5W
Power Off Mode : <0.3W
Voltage : 100-240V, 50/60Hz
Power Saving Mode : <0.5W
Power Off Mode : <0.3W
Voltage : 100-240V, 50/60Hz
Mechanical Design
Tilt : Yes (+15° ~ +35°)
Height Adjustment : No
1/4" Tripod Socket : Yes
Height Adjustment : No
1/4" Tripod Socket : Yes
Dimensions (Esti.)
Phys. Dimension without Stand (W x H x D) : 35.99 x 22.68 x 1.20 cm (14.17" x 8.93" x 0.47")
Box Dimension (W x H x D) : 48.50 x 30.50 x 7.60 cm (19.09" x 12.01" x 2.99")
Box Dimension (W x H x D) : 48.50 x 30.50 x 7.60 cm (19.09" x 12.01" x 2.99")
Weight (Esti.)
Net Weight without Stand : 1.01 kg (2.23 lbs)
Gross Weight : 2.86 kg (6.31 lbs)
Gross Weight : 2.86 kg (6.31 lbs)
Accessories (vary by regions)
Mini HDMI to HDMI cable
Power adapter
Quick start guide
USB-C cable
USB-C to A cable
Warranty Card
ZenScreen sleeve
ZenScreen tripod hole cover
Power adapter
Quick start guide
USB-C cable
USB-C to A cable
Warranty Card
ZenScreen sleeve
ZenScreen tripod hole cover
Operation Temperature / Humidity
Operation temperature : 0~40℃
Operation humidity : 20-90% RH
Operation humidity : 20-90% RH
Certificate
Energy Star
TÜV Flicker-free
TÜV Low Blue Light
TÜV Flicker-free
TÜV Low Blue Light
