Exclusive featuresASRock Super Alloy
- Advanced Inductor
- Glossy Black PCB
- High Density Moisture-Proof Fiber Circuit Board
ASRock Ultra M.2 (PCIe Gen3x4)
ASRock Full Protection (Supports all USB, audio, and network ports)
ASRock Live Update & APP Shop -
processor- Supports 13th and 12th generation and next-generation Intel ® Core™ processors (LGA1700)
- 6+1+1 power phase design
- Supports Intel ® Hybrid Technology
- Supports Intel ® Turbo Boost Max 3.0 technology -
chip- Intel ® H610
-
Memory- Dual channel DDR4 memory technology
- 2 x DDR4 slots
- Supports DDR4 non-ECC, un-buffered memory up to 3200
- Supports ECC UDIMM memory modules (non-ECC mode)
- Maximum system memory capacity: 64GB *
- Supports Intel ® Extreme Memory Profile (XMP) 2.0 technology
* Due to operating system limitations, the actual usable memory under Windows ® 32-bit operating system will be less than 4GB. This restriction does not apply to 64-bit CPUs under Windows ® 64-bit operating systems. -
BIOS- 128Mb AMI UEFI Legal BIOS, supports multi-language graphical interface
- ACPI 6.0 compliant, supports wake-up and automatic boot (Wake Up Events)
- supports SMBIOS 2.7
- CPU core/cache, CPU core/cache load line, CPU GT, CPU GT load line, DRAM, +0.82V PCH, +1.05V PCH, VCCIN AUX, +1.8V PROC, +1.05V PROC voltage multi-function regulator -
built-in display- Intel ® _ _
_
_
_ DCS (compression technology), maximum resolution up to 8K (7680x4320) @ 60Hz / 5K (5120x3200) @ 120Hz -
Supports D-Sub, maximum resolution up to 1920x1200 @ 60Hz
- HDMI 2.1 TMDS Compatible and DisplayPort 1.4 interface supporting HDCP 2.3
* Processors with built-in GPU functionality support Intel® UHD display chips with built-in visual enhancement functionality and display output. -
Sound effects- 7.1-channel high-fidelity audio (Realtek ALC897 audio codec)
- Anti-surge -
network- PCIE x1 Gigabit network card 10/100/1000 Mb/s
- 1 x Realtek RTL8111H
- Supports Wake-On-LAN function
- Supports lightning protection/anti-ESD static electricity
- Supports Energy Efficient Ethernet 802.3az
- Supports PXE -
Expansion slotCPU:
- 1 x PCIe 4.0 x16 slot (PCIE2), supports x16 mode *
Chipset:
- 1 x PCIe 3.0 x1 slot (PCIE1)
* Supports NVMe SSD boot -
storeChipset:
- 1 x Ultra M.2 slot (M2_2, Key M), supports type 2242/2260/2280 PCIe Gen3x4 (32 Gb/s) mode* - 4
x SATA3 6.0 Gb/s ports
* Supports NVMe SSD and
supports ASRock U.2 kit when booting -
Connector- 1 x SPI TPM header
- 1 x chassis startup warning function header and speaker header
- 1 x CPU fan connector port (4-pin) *
- 1 x chassis/water pump fan interface (4-pin) (smart fan Speed Control) **
- 1 x 24-pin ATX power port
- 1 x 8-pin 12V power port
- 1 x Front Panel Audio port
- 1 x USB 2.0 header (supports 2 USB 2.0 ports) (supports ESD static electricity protection)
- 1 x USB 3.2 Gen1 header (supports 2 USB 3.2 Gen1 ports) (supports ESD protection)
* The CPU fan connector supports up to 1A (12W) power supply.
** The case/water pump fan supports up to 2A (24W) water cooling fan.
CHA_FAN1/WP can automatically detect 3-pin or 4-pin fans. -
Rear panel output/input interface- 1 x PS/2 keyboard/mouse port
- 1 x D-Sub port
- 1 x HDMI port
- 1 x DisplayPort 1.4
- 2 x USB 3.2 Gen1 ports (supports ESD protection)
- 4 x USB 2.0 ports (supports ESD ESD protection)
- 1 x RJ-45 network port with LED indicators (ACT/LINK LED and SPEED LED)
- HD audio jack: line in/front speakers/microphone -
Software and UEFISoftware
- ASRock Motherboard Utility (A-Tuning)
- ASRock XFast LAN
UEFI
- ASRock EZ Mode
- ASRock Full HD UEFI
- ASRock My Favorite UEFI
- ASRock Instant Flash
* These apps can be downloaded from ASRock APP Shop. -
random disc- Drivers, application software, anti-virus software (trial version)
-
appendix- Quick installation guide, support CD, I/O cover
- 2 x SATA cable
- 1 x M.2 slot screw -
Hardware monitoring- Fan tachometer: CPU, case/water pump fan
- Silent fan (automatically adjusts case fan speed based on CPU temperature): CPU, case/water pump fan
- Fan multi-speed control: CPU, case/water pump fan
- Case opening detection
- Voltage Real-time monitoring: CPU core, memory, +0.82V PCH, +1.05V PCH, VCCIN AUX, VCCSA, +1.05V PROC, +12V, +5V, +3.3V -
Specification- Micro ATX dimensions: 8.66-in x 7.6-in, 22.0 cm x 19.3 cm
- Solid capacitive design -
operating system- Support Microsoft ® Windows 10 64-bit / 11 64-bit
-
Certification- FCC, CE
- Supports ErP/EuP (requires a power supply that supports ErP/EuP)
