| main spec |
| Dimensions |
522 x 230 x 522 mm (DWH) |
| Form Factor |
Full Tower |
| Materials |
Steel + Plastic + Glass |
| Mainboard Support |
E-ATX, ATX, Micro-ATX, ITX |
| Front Access & Controls |
Power, Reset , USB 3.0 x 2, Type-C 10Gbps x 1, Headphone/Mic Combo Jack, Temp. Display Switch x 1 |
| Side Panel |
4mm Tempered Glass(Both Sides) |
|
| Drive Bays |
| Expansion Slots |
8 |
| 3.5" / 2.5" |
2 / 2 |
| 2.5" |
3 |
|
| Fan Support |
| Front |
3 x 120mm / 3 X 140mm |
| Top |
3 x 120mm / 3 x 140mm |
| Power Supply Shroud |
3 x 120mm |
| Rear |
1 x 120mm |
| Included Fan(s) |
3 x 140 x 30mm PWM fans in front + 1 x 120 x 30mm PWM fan in rear
Pre-installed Storm T3 PWM fan specs vary from the retail version |
|
| Radiator Support |
| Front |
120 / 140 / 240 / 280 / 360 / 420mm |
| Top |
120 / 140 / 240 / 280 / 360mm |
| Rear |
120mm |
|
| Clearance |
| Max GPU Length |
≤ 400mm |
| Max CPU Cooler Height |
≤ 175mm |
| Max PSU Length |
(Include cable) ≤ 245mm(with HDD)
(Include cable) ≤ 440mm(without HDD) |
|
| Miscellaneous |
| Dust Filter |
Front / Top / Bottom |
| Net Weight |
12.55Kgs |
| Gross Weight |
14.85Kgs |
|
