Physical
| Socket: | AMD Socket sTR5 |
|---|---|
| Foundry: | TSMC |
| Process Size: | 5 nm |
| Transistors: | 78,840 million |
| Die Size: | 12x 71 mm² |
| I/O Process Size: | 6 nm |
| I/O Transistors: | 11,000 million |
| I/O Die Size: | 388 mm² |
| Package: | FC-LGA4844 |
| tJMax: | 95°C |
Performance
| Frequency: | 2.5 GHz |
|---|---|
| Turbo Clock: | up to 5.1 GHz |
| Base Clock: | 100 MHz |
| Multiplier: | 25.0x |
| Multiplier Unlocked: | Yes |
| TDP: | 350 W |
Architecture
| Codename: | Storm Peak |
|---|---|
| Generation: |
Ryzen Threadripper (Zen 4 (Storm Peak)) |
| Memory Support: | DDR5 |
| Max. Memory: | 2 TB (ECC RDIMM only) |
| Rated Speed: | 5200 MT/s |
| Memory Bus: | Eight-channel |
| ECC Memory: | Yes |
| PCI-Express: | Gen 5, 128 Lanes (CPU only) |
| Secondary PCIe: | Gen 3, 8 Lanes |
| Chipset PCIe: | Gen 4, 8 Lanes |
| Chipsets: | WRX90, TRX50, Pro 695 |
Core Config
| # of Cores: | 96 |
|---|---|
| # of Threads: | 192 |
| SMP # CPUs: | 1 |
| Integrated Graphics: | N/A |
Cache
| Cache L1: | 64 KB (per core) |
|---|---|
| Cache L2: | 1 MB (per core) |
| Cache L3: | 384 MB (shared) |
