Description
| CPU | Intel® Core™ Ultra X7 Processor 358H Intel® Core™ Ultra Series 3 (Panther Lake) 16 Cores / 16 Threads, Intel 18A Process Performance-cores (4C) Base: 1.9 GHz / Max Turbo: 4.8 GHz Efficient-cores (8C) Base: 1.5 GHz / Max Turbo: 3.5 GHz Low Power Efficient-cores (4C) Base: 1.5 GHz / Max Turbo: 3.3 GHz 18MB Intel® Smart Cache Power Modes: 35W (Silent) / 45W (Balanced) / 54W (Performance), Peak 60W VC Cooling + Dual Fan Design (Support RGB Lighting) |
|---|---|
| CPU Package | FCBGA2540 Package Size: 50mm × 25mm |
| GPU | Intel® Arc™ B390 GPU 12 Xe-Cores, Ray Tracing Supported Max Dynamic Frequency: 2.5 GHz Peak AI Performance: 122 TOPS (INT8) |
| NPU | Built-in NPU, up to 50 TOPS (INT8) |
| Memory | LPDDR5X up to 8533 MT/s 64GB (Onboard) |
| Storage | Option 1: • M.2 2280 NVMe PCIe 5.0 ×4 SSD • Phison AI SSD 853GB (768GB + 85GB) Option 2: • M.2 2280 NVMe PCIe 4.0 ×4 SSD (1TB) |
| Internal Expansion | Dual M.2 2280 Slots • 1× PCIe 5.0 ×4 • 1× PCIe 4.0 ×1 Max Capacity: 8TB ×2 |
| Video Output | HDMI + DP + Dual USB4 Supports up to 8K Resolution |
| Network | Wi-Fi 7 (RZ717, up to 2.9Gbps) Bluetooth 5.4 10G LAN + 2.5G LAN |
| Front I/O | • 1× USB4 Type-C (PD 3.0, 100W Input / DP 4K@60Hz / 40Gbps) • 2× USB 3.2 Gen2 Type-A (10Gbps) • 1× USB 2.0 Type-A (480Mbps) • 1× 3.5mm Audio Combo Jack |
| Rear I/O | • 1× USB4 Type-C (PD 3.0, 100W Input / DP 4K@60Hz / 40Gbps) • 2× USB 2.0 Type-A • 1× HDMI 2.1 TMDS (4K@60Hz) • 1× DP 1.4 (8K@60Hz, DP++) • 1× OCuLink (PCIe 4.0 ×4, No Hot Swap) • 1× 10G RJ45 LAN • 1× 2.5G RJ45 LAN • 1× DC IN (5.5 × 2.5mm) • 1× Kensington Lock Slot |
| Power | DC IN: 19V ⎓ 7.8A Built-in CMOS Battery |
| Dimensions | 154 × 151 × 73.6 mm |
| Weight | Approx. 2.3 kg |
| OS Support | Windows 11 Pro Ubuntu / Linux |
