Technical Spec :
Heatsink Specifications:
Dimension：L140 mm x W121 mm x H158 mm
Weight：1000g
Heat pipes：8mm heatpipe x 5 units
Fin：T = 0.4 mm；Gap=1.8 mm
Copper Base：C1100 Pure copper nickel plated
TL-C12 PRO FAN Spec：
Dimension：L120 mm x W120 mm x H25 mm
Weight：165g
Rated Speed：1850 RPM±10% (MAX)
Noise Level：29.6 dBA
Air Flow：82 CFM (MAX)
Air Pressure：2.1mm H2O (MAX)
Ampere：0.25 A
Connector：4 Pin (PWM Fan connector)
Bearing Type : S-FDB Bearing
TL-D14X-B FAN Spec：
Dimension：L140 mm x W152 mm x H27 mm
Weight：175g
Rated Speed：1800 RPM±10% (MAX)
Noise Level：30.2 dBA
Air Flow：95.5 CFM (MAX)
Air Pressure：2.25mm H2O (MAX)
Ampere：0.30 A
Connector：4 Pin (PWM Fan connector)
Bearing Type : S-FDB Bearing
