| Product Name |
HCG1000 Gold |
| Model Name |
HCG1000 Gold |
| Type |
ATX 12V 2.4 |
| Modular |
Fully Modular |
| Dimension (W x L x H) |
160(L) x 150(W) x 86(H) |
| Warranty |
10 years |
| Input Voltage |
100-240 VAC ±10% |
| Input Current |
13A-6.5A |
| Input Frequency Range |
50Hz-60Hz |
| PFC |
Active PFC (>0.9 typical) |
| Power Good Signal |
100-500ms |
| Efficiency |
92% Typically |
| Protection |
OCP / OVP / UVP / SCP / OPP / OTP / SIP / NLO |
| Output Capacity |
1000W |
| Operation Temperature |
0~50°C |
| Regulatory |
cTUVus / TUV / CB / RCM / CE / EAC / CCC / BSMI / FCC / KR / BIS / UKCA / ICES |
| Fan |
135 mm FDB Fan |
| Certifications |
80 Plus Gold |
| Connector |
1 x MB 24(20+4) Pin |
| 2 x 8(4+4) Pin EPS 12V |
| 8 x 8(6+2) Pin PCI-E |
| 12 x SATA |
| 6 x Molex |
| 1 x FDD |
| Net Weight |
1.88 Kgs |
| Gross Weight |
3.61 Kgs |
